Pipeline Magnetic Separator
High-Pressure Magnetic Filtration for Liquid & Slurry Processing
Engineered for efficient removal of ferrous metal contamination from viscous liquids, pastes, and slurry pipelines.
The Pipeline Magnetic Separator is specifically designed to remove iron particles from liquid and semi-liquid products moving through pressurized pipelines. Equipped with a high-intensity magnetic cartridge inside a robust stainless-steel housing, it captures fine metallic impurities from high-viscosity materials such as chocolate syrup, dairy products, paints, oils, fruit pulp, and ceramic slurry.
Its powerful Rare Earth NdFeB magnets ensure superior separation efficiency, improving product purity and protecting downstream equipment including pumps, homogenizers, heat exchangers, and fillers. This makes it an essential component for industries requiring hygiene, safety, and consistent product quality.
Technical Specifications
| Specification | Details |
|---|---|
| Pipeline Size | 1” – 12” |
| Magnet Strength | 8000 – 12000 Gauss |
| Magnet Type | Rare Earth NdFeB |
| Design Pressure | Up to 12 Bar (higher on request) |
| Construction Material | SS304 / SS316 Food Grade |
| Internal Cartridge | Tri-Cone / Bullet-Style Magnetic Core |
| Cleaning System | Manual / Easy-Clean / Hydraulic Clean |
| Temperature Range | Up to 120°C (High temperature version available) |
| Connection Type | SMS / BSP / Flange / TC Clamp |
| Flow Compatibility | Liquids, slurry, semi-solids & pastes |
Key Features
- High-intensity magnetic core captures fine ferrous impurities
- Suitable for high-pressure pipeline operations
- Hygienic stainless-steel design for food & pharma
- Quick-release clamp for fast access & cleaning
- Smooth internal flow path reduces pressure drop
- Heavy-duty construction for long service life
- Customizable sizes & end connection types
Advantages
- Improves purity & final product quality
- Prevents pump, valve & heat exchanger damage
- Reduces maintenance downtime & production loss
- Works in continuous 24/7 processing
- Long-life magnets with low operating cost
- Supports CIP (Clean-In-Place) compatibility
Applications
- Food & Beverage: Fruit pulp, juice, dairy, chocolate syrup
- Pharmaceuticals: Liquid suspensions & solutions
- Chemicals: Paint, latex, solvents, adhesives
- Minerals: Ceramic slurry, kaolin, clay
- Oil & Petrochemicals: Lubricants & hydraulic fluids
- Agriculture: Fertilizer liquids & cattle-feed slurry
