Inline Magnetic Separator
High-Intensity Magnetic Filtration for Gravity & Pneumatic Lines
Designed to capture ferrous particles directly in vertical pipelines, gravity chutes & inline material transfer systems.
The Inline Magnetic Separator is a compact and efficient magnetic separation unit designed for gravity-fed and pneumatic conveying applications. Installed directly into the product flow path, it ensures continuous removal of fine ferrous contaminants without interrupting production.
Equipped with a high-intensity Rare Earth NdFeB magnetic assembly, this separator offers excellent metal capture efficiency, enhancing product purity and protecting downstream processing equipment. It is widely used in food, plastics, chemical, mineral, and powder handling industries where inline contamination control is critical.
Technical Specifications
| Specification | Details |
|---|---|
| Magnet Strength | 6000 – 11000 Gauss |
| Construction Material | SS304 / SS316 |
| Internal Magnet Type | Rare Earth NdFeB |
| Inlet / Outlet Size | Custom as per line size |
| Working Type | Inline Gravity / Pneumatic conveying |
| Cleaning | Manual & Easy-clean options |
| Mounting Position | Vertical / Inclined pipelines |
| Temperature Range | Up to 120°C |
Key Features
- High magnetic power for fine contamination capture
- Inline separation without production stoppage
- Robust stainless steel food-grade design
- Smooth internal flow path prevents bridging
- Quick access for cleaning and maintenance
- Low pressure drop across the system
- Customizable inlet & outlet sizes
Advantages
- Improves final product quality
- Protects downstream machinery (mills, extruders, grinders)
- Very low maintenance and operating cost
- Increased processing efficiency and plant safety
- Compact & easy to integrate with existing systems
Applications
- Food & Beverage: Flour, grains, rice, spices, coffee
- Plastic & Polymer: PVC, PET, HDPE, LDPE granules & powders
- Chemical & Pharma: Additives, minerals & powder blends
- Minerals & Ceramics: Silica, talc, feldspar
- Agriculture & Fertilizer: Granules & powders
