Magnetic Roll Separator
Precision Separation of Weak Magnetic Minerals
Engineered for high-purity mineral processing and industrial separation applications.
The Magnetic Roll Separator is designed for accurate separation of weakly magnetic particles from dry granular materials. Using high-intensity rare-earth magnetic rolls combined with adjustable belt speed, the system delivers maximum separation efficiency.
It is ideal for minerals, refractory materials, abrasive powders, and various industrial raw materials requiring superior purity levels during processing.
Technical Specifications
| Specification | Details |
|---|---|
| Magnetic Roller | Single / Double / Triple Stage |
| Magnet Strength | 12,000 – 18,500 Gauss |
| Roll Width | 300–1500 mm |
| Belt Type | Endless Belt |
| Belt Speed | Variable 0–100 RPM |
| Drive Motor | 2 HP – 7.5 HP |
| Body Material | Mild Steel / Stainless Steel |
| Feeding System | Vibratory Feeder |
Key Features
- High-intensity magnetic field
- Adjustable belt speed & feed rate
- Stable performance & long service life
- Precision rotary separation structure
Advantages
- Very high recovery rate
- Ideal for fine-grade material processing
- Low operational cost & maintenance
- Compact design with low power usage
Applications
- Minerals: Feldspar, Quartz, Silica Sand
- Mining: Bauxite, Iron Ore, Manganese
- Diamond: Concentration & beneficiation
- Refractory: Abrasive material separation
